    Q235 Material Earth Auger Anchors 48" 5/8" Rod With 6" Helix Painted

    Ask Lasest Price
    Brand Name : NTS
    Model Number : NTS212
    Certification : ISO9001 CE
    Price : as discussed
    Supply Ability : 50000per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Q235 Material Earth Auger Anchors 48" 5/8" Rod With 6" Helix Painted

    High Quality 48" 5/8" Rod with 6" Helix Painted Auger Earth Anchor


    Product Information

    Professional Grade Earth Anchor
    • Helix OD: 6"
    • Length: 48"
    • Rod Diameter: 5/8"
    • Finish: Painted
    • Approx. Holding Capacity (see notes): 4,000 lbs.*
    • Shipping Weight: 6.2 lbs.
    • Ships Common Carrier only.
    • One piece Auger Earth Anchors may be used to attach guy wires for securing structures such as metal buildings, tents, docks; for anchoring erosion control barriers as well as for many other applications. Anchors are installed by turning the anchor into the ground, utilizing a turning bar placed through the anchor's welded eye. Anchors can be installed by hand or by machine. Anchors have a welded eye, heavy duty helix welded on both sides and an angled point to ease installation.
      *Holding Capacity: Auger Earth Anchors correctly installed in normal soils.
      Holding capacity is dependent on soil conditions and density. Special installation consideration must be taken in rocky soils. To achieve optimal holding capacity auger anchors must be screwed deeply into the ground. After inserting a metal rod through the anchor eye, screw the anchor into the ground or use a power driver. Anchor must be installed in line with the direction of the guy load. Anchor can also be imbedded in concrete for a more permanent installation.

    SPECIFICATION FOR AUGER EARTH SCREW ANCHOR

    Item Earth anchor

    G.W. (kg)

    N.W. (kg)

    Cube (foot)

    40' container

    40'floor loaded container

    15"-3"*9/16

    1.76

    1.54

    0.04

    24800

    25000

    30"-3"*9/16

    2.64

    2.42

    0.08

    16500

    17000

    40"-4"*9/16

    3.74

    3.3

    0.14

    11500

    11788

    48"-6"*5/8

    5.94

    5.5

    0.35

    5328

    6080

    15"-3"*3/8

    1.1

    0.92

    0.04

    38880

    47150

    15"-3"*1/2

    1.43

    2.32

    0.04

    28500

    29200

    30"-4"*1/2

    2.64

    2.42

    0.11

    16500

    16600


    Here are the pictures of the helix anchor

    DETAILS VIEW OF THE OFFSET EYE WELDING QUALITY

    DETAILED VIEW OF WELDED HELIX BLADE TO THE ROD


    Packing pictures: packing size and quantity depends on the rod and plate diameter


    Our Services

    Pro-service:

    • detailed answers about our factory and our products
    • reasonable recommendation
    • OEM/ODM

    service:

    We can product as Customers' requirements, incoluding color, appearance, etc.


    After-service:

    • The packing way could according to customer request
    • With the fastest speed of delivery
    • any problem pls contact us , we will give you good resolve at first time.
