Galvanized Forged Steel Ground Anchor Helix Ground Anchor For Earth Ground Anchor

Product Information

1. Heavy Duty 1 1/4″ x 66” with 10” Helix “Galvanized” Screw Anchor Heavy duty 1 1/4″ Shaft and Formed Triple closed Eye

Ideal for corrosive environments in medium to soft Soils – “Hot dipped Galvanized Finish”

2. ground anchor is Commonly used for Mooring Boats and docks, securing vineyard trellises, Large storage
sheds, retaining walls, radio antennas,small windmills, Long Hop runs

3. helix ground anchor Holding strength is based on clay soils which are of hard to medium density. The holding strength is reduced in softer less dense soils and sandy soils.

4. To ensure maximum holding strength, anchor must be installed to full depth with the bottom of eyelet at ground level.

5. Can be installed by hand in softer soils with a “installation bar” harder soils may need power installation equipment

12,000 lb+ pull out resistance in Hard Pan soils- less in less dense soils

Specifications:

Finish: Hot Dip Galvanized

Shaft Diameter: 11/4″

Helix: Single 10″

ID of Eye: 1 1/2″ Forged

Length: 66″ 96"

Earth Screw Helix Anchor dimension and catalogue:

CODE	SIZE	ROD DIA	LENGTH	HELIX	TENSILE STRENGTH
NTS-1513	1"	25mm	54"	6"	9000lbs
NTS-1514	1"	25mm	66"	8"	9000lbs
NTS-1515	1"	25mm	72"	10"	10000lbs
NTS-1516	1"	25mm	96"	10"	10000lbs
NTS-1517	1 1/4"	31.7mm	66"	8"	9000lbs
NTS-1518	1 1/4"	31.7mm	72"	10"	10000lbs
NTS-1519	1 1/4"	31.7mm	96"	10"	10000lbs
NTS-1520	1 1/4"	31.7mm	96"	12"	11000lbs

Customizing is welcome!
